| v.lenzer Senior Member  Joined: 04/05/2024 Location: GermanyPosts: 123 |
Wenn man bei Mouser (Deutschland) eingetragen ist, kann man das Gehäuse Hammond RM20215S als STP-Datei herunterladen und drucken (https://www.mouser.de/ProductDetail/Hammond-Manufacturing/RM2015S?qs=6W4OQKoqJ0vbaS7wWejjkQ%3D%3D). Das ist ein toller Support von Mouser! Allerdings sollte man auf dem Boden die Abschrägung nach unten ziehen, damit nicht soviele Supports gedruckt werden müssen. Ich denke, das ist das Gehäuse, das Peter verwendet hat. If you have an account with Mouser (Germany), you can download the Hammond RM20215S enclosure as an STP file and print it (https://www.mouser.de/ProductDetail/Hammond-Manufacturing/RM2015S?qs=6W4OQKoqJ0vbaS7wWejjkQ%3D%3D). It's a great support from Mouser. However, you should extend the bevel on the bottom downwards so that fewer supports are required during printing. I believe this is the enclosure Peter used.  Edited 2026-07-10 21:23 by v.lenzer Best wishes! Joachim |
||||
| v.lenzer Senior Member Joined: 04/05/2024 Location: GermanyPosts: 123 |
Ich nehme noch ein komplettes Set dazu. Die Liste habe ich ergänzt. User | Name |Loc.|No.ofPC3s|hdmi2VGA|panels|case|Aug.OK?|comment homa57 | Matthias | DE | 2 | 1 | 2 | 2 | yes | v.lenzer | Joachim | DE | 3 | 3 | 3 | 3 | yes | bigfix | Guenter | AT | 3 | 3 | 3 | 3 | yes |delivery AT Arne | Arne | DE | 2 | 2 | 2 | 2 | yes | ManiB | Manfred | DE | 5 | 5 | 5 | 5 | yes | Gerad | Gerad | DE | 3 | 3 | 3 | 3 | yes | Martin H. | Martin | DE | 1 | - | - | - | yes | karlelch | Thomas | DE | 1 | - | 1 | 1 | yes | Frank N. Furter| Frank | DE | 1 | 1 | 1 | 1 | yes | tom_g | Thomas | CH | 1 | 1 | - | - | yes |delivery DE ville56 | Gerald | AT | 1 | 1 | 1 | 1 | yes |delivery AT ---------------------------------------------------------------------------------- 23 20 21 21 must be ordered by me 25 20 23 23 Best wishes! Joachim |
||||
| hhtg1968 Senior Member Joined: 25/05/2023 Location: GermanyPosts: 206 |
is it still possible to order? User | Name |Loc.|No.ofPC3s|hdmi2VGA|panels|case|Aug.OK?|comment hhtg1968 | Heinrich | DE | 1 | - | 1 | 1 | yes |delivery DE |
||||
homa Guru  Joined: 05/11/2021 Location: GermanyPosts: 650 |
User | Name |Loc.|No.ofPC3s|hdmi2VGA|panels|case|Aug.OK?|comment homa57 | Matthias | DE | 3 | 1 | 2 | 2 | yes | v.lenzer | Joachim | DE | 3 | 3 | 3 | 3 | yes | bigfix | Guenter | AT | 3 | 3 | 3 | 3 | yes |delivery AT Arne | Arne | DE | 2 | 2 | 2 | 2 | yes | ManiB | Manfred | DE | 5 | 5 | 5 | 5 | yes | Gerad | Gerad | DE | 3 | 3 | 3 | 3 | yes | Martin H. | Martin | DE | 1 | - | - | - | yes | karlelch | Thomas | DE | 1 | - | 1 | 1 | yes | Frank N. Furter| Frank | DE | 1 | 1 | 1 | 1 | yes | tom_g | Thomas | CH | 1 | 1 | - | - | yes |delivery DE ville56 | Gerald | AT | 1 | 1 | 1 | 1 | yes |delivery AT hhtg1968 | Heinrich | DE | 1 | - | 1 | 1 | yes | ---------------------------------------------------------------------------------- 25 20 22 22 Orders for “PC3s” and “hdmi2VGA” are now closed; this fits in perfectly with the tiered pricing structure of the supplier jlcpcb! |
||||
| homa Guru Joined: 05/11/2021 Location: GermanyPosts: 650 |
@ManiB: Die Blenden in schwarz sind für mich okay und auch default gewählt. Welche Stärke hast du da im Bild verwendet? 1.6 oder 2 mm? Bei der Platinenfarbe bevorzuge ich grün, dann kann man viel besser die Leiterbahnen verfolgen und hat im Falle eines Falles noch eine Chance. Es ist doch eh der Deckel drauf ;-) @ManiB: The black panels are fine by me – that’s my default setting anyway. What thickness did you use in the picture? 1.6 or 2 mm? As for the colour of the circuit board, I prefer green – it makes the tracks much easier to follow, and you still have the option of repairing something if the worst comes to the worst. The board is covered by the casing anyway ;-) |
||||
| v.lenzer Senior Member Joined: 04/05/2024 Location: GermanyPosts: 123 |
Für die Druckvariante des Gehäuses (und vermutlich auch für die Kaufvariante) ist die Frontplattenstärke 1,6 mm. For the printable version of the enclosure (and presumably for the purchased version as well), the front panel thickness is 1.6 mm. Edited 2026-07-13 19:39 by v.lenzer Best wishes! Joachim |
||||
Martin H. Guru Joined: 04/06/2022 Location: GermanyPosts: 1472 |
Hab schon angefangen mir eine Selbstdruckvariante zu erstellen, die genauen Maße für Stützen etc. kann ich aber erst eintragen wenn ich das Board habe. Ich hab die Schrift 3mm erhaben gemacht, so kann man den Druck Pausieren und das Filament wechseln,oder einfach später die oberflächen mit Edding anmalen  Cheers Martin Edited 2026-07-13 21:36 by Martin H. 'no comment |
||||
Mixtel90 Guru Joined: 05/10/2019 Location: United KingdomPosts: 8947 |
From my own experiments I think the actual ideal thickness is 1.5mm! For a while now I've been getting panels made as PCBs using 1.6mm material but removing the copper in a strip round the edges of both sides. This brings the thickness down nicely and you don't get a query about why there isn't any copper. It also means that you have the choice of screening the panels by soldering a wire to the inner copper. Mick Zilog Inside! nascom.info for Nascom & Gemini Preliminary MMBasic docs & my PCB designs |
||||
