Martin H.

Guru

Joined: 04/06/2022
Location: Germany
Posts: 1472
Posted: 08:04pm 07 Jul 2026
Copy link to clipboard
Print this post

  Frank N. Furter said
  homa said  Please check the options; delivery costs will be added on top.


Martin H.       | Martin   | Germany | 2           |          |        |      |               | fully equipped boards

@Frank,
kleine Korrektur, mir reicht ein PC3 fully equipped boards, nicht 2
Danke für die Zusammenfassung
Liebe Grüße
Martin
  Quote  Just a quick correction – one fully equipped PC3 board is enough for me, not two.
thanks for the summary
Best regards,
Martin

Edited 2026-07-08 06:04 by Martin H.
'no comment

Gerad
Regular Member

Joined: 10/01/2024
Location: Germany
Posts: 56
Posted: 08:17pm 07 Jul 2026
Copy link to clipboard
Print this post

Hallo Matthias

eine kurze Frage: Wie bezahle Ich die bestellten Boards etc. ? Überweisung, Kreditkarte
?


Grüsse Gerad

Arne
Regular Member

Joined: 05/01/2025
Location: Germany
Posts: 52
Posted: 08:39pm 07 Jul 2026
Copy link to clipboard
Print this post

Hi Matthias,

Options/List is ok. Joining in August is ok too.

Thank you for ordering,

Arne

homa

Guru

Joined: 05/11/2021
Location: Germany
Posts: 650
Posted: 10:14pm 07 Jul 2026
Copy link to clipboard
Print this post

  matherp said  The case is the same as always. MULTICOMP MCRM2015S mostly available from Element14/Farnell or the HAMMOND RM2015S available from DigiKey, Mouser, etc.
I've got some nice PCB end-plates but, with apologies, I can't remember who sent me them - Geoff, Grogster (maybe on Silicon Chip)? but there are designs out there. What I have got is the original dxf files for the end-plates which can be used to laser-cut, 3d print, or create PCB designs.


Hi Peter, could you please upload the DXF file? Perhaps someone could use it to create suitable PCB designs!
Many thanks in advance.

tom_g
Newbie

Joined: 21/02/2023
Location: Switzerland
Posts: 22
Posted: 12:27am 08 Jul 2026
Copy link to clipboard
Print this post

Lieber Matthias,

User            | Name     | Location | No. of PCBs | hdmi2VGA | panels | case | joining in Aug | comment
tom_g           | Thomas   | Germany | 1           | 1        | 0      | 0    | yes | *


(* ich besitze eine Grenzpaket-Adresse in DE, max. Freibetrag 150Euro beim Selbstimport nach CH, darueber muss ich verzollen)

Vorauszahlung OK

Liebe Gruesse von Thomas HB9TOM
Edited 2026-07-08 10:34 by tom_g

ManiB
Senior Member

Joined: 12/10/2019
Location: Germany
Posts: 144
Posted: 06:23am 08 Jul 2026
Copy link to clipboard
Print this post

Hi Matthias,


could you please update my order to 5 x "Full House" versions with all options?


ManiB | Manfred | Germany | 5 | 5 | 5 | 5 | | Please use lead-free HASL PCBs


Thanks a lot ;)


P.S., I mentioned the “lead-free HASL PCBs” because, legally speaking, items imported into Germany are not allowed to contain lead.

Frank N. Furter
Guru

Joined: 28/05/2012
Location: Germany
Posts: 1142
Posted: 06:36am 08 Jul 2026
Copy link to clipboard
Print this post

  Martin H. said
  Frank N. Furter said
  homa said  Please check the options; delivery costs will be added on top.


Martin H.       | Martin   | Germany | 2           |          |        |      |               | fully equipped boards

@Frank,
kleine Korrektur, mir reicht ein PC3 fully equipped boards, nicht 2
Danke für die Zusammenfassung
Liebe Grüße
Martin
  Quote  Just a quick correction – one fully equipped PC3 board is enough for me, not two.
thanks for the summary
Best regards,
Martin


I just copied the list from the previous post...

Frank

homa

Guru

Joined: 05/11/2021
Location: Germany
Posts: 650
Posted: 04:24pm 08 Jul 2026
Copy link to clipboard
Print this post

Update:


User           | Name     |Loc.|No.ofPC3s|hdmi2VGA|panels|case|Aug.OK?|comment
homa57         | Matthias | DE | 2        | 1      | 2   | 2  | yes   |
v.lenzer       | Joachim  | DE | 2        | 2      | 2   | 2  |       |
bigfix         | Guenter  | AT | 2-3      | 2-3    | 2-3 | 2-3|       | i selected 3
Arne           | Arne     | DE | 2        | 2      | 2   | 2  |       |
ManiB          | Manfred  | DE | 5        | 5      | 5   | 5  | yes   |
Gerad          | Gerad    | DE | 3        | 3      | 3   | 3  | yes   |
Martin H.      | Martin   | DE | 1        | -      | -   | -  | yes   |
karlelch       | Thomas   | DE | 1        |        |     |    |       |
Frank N. Furter| Frank    | DE | 1        | 1      | 1   | 1  | yes   |
tom_g          | Thomas   | CH | 1        | 1      | -   | -  | yes   |delivery DE
ville56        | Gerald   | AT | 1        | 1      | 1   | 1  |       |
                                22         18     18   18


Payment can be made via PayPal or bank transfer. More details to follow.
Die Zahlung kann per PayPal oder Banküberweisung erfolgen. Details später.

Please write "yes" if you're still in – thanks.
Bitte "yes" bei "August OK?" eintragen wer dabei bleibt, danke.

The housing appears to be cheapest at DigiKey:
Das Gehäuse scheint bei DigiKey am günstigsten zu: https://www.digikey.de/de/products/detail/hammond-manufacturing/RM2015S/2094831

Martin H.

Guru

Joined: 04/06/2022
Location: Germany
Posts: 1472
Posted: 05:09pm 08 Jul 2026
Copy link to clipboard
Print this post

"yes"
'no comment

Frank N. Furter
Guru

Joined: 28/05/2012
Location: Germany
Posts: 1142
Posted: 05:16pm 08 Jul 2026
Copy link to clipboard
Print this post

@homa:

Bitte trage bei mir auch ein "YES" ein.
Please enter "YES" for me as well.


Frank

Arne
Regular Member

Joined: 05/01/2025
Location: Germany
Posts: 52
Posted: 06:23pm 08 Jul 2026
Copy link to clipboard
Print this post

August is ok !

„yes“

Arne

bigfix
Senior Member

Joined: 20/02/2014
Location: Austria
Posts: 132
Posted: 08:09pm 08 Jul 2026
Copy link to clipboard
Print this post

Yes, yes ...

I am fine with everything proposed
Make my number of boards "3" as you got a large number anyhow

Just ping me with the final price and you will get it asap

best
Guenter
Edited 2026-07-09 06:10 by bigfix

homa

Guru

Joined: 05/11/2021
Location: Germany
Posts: 650
Posted: 08:30pm 08 Jul 2026
Copy link to clipboard
Print this post

Update:


User           | Name     |Loc.|No.ofPC3s|hdmi2VGA|panels|case|Aug.OK?|comment
homa57         | Matthias | DE | 2        | 1      | 2   | 2  | yes   |
v.lenzer       | Joachim  | DE | 2        | 2      | 2   | 2  |       |
bigfix         | Guenter  | AT | 3        | 3      | 3   | 3  | yes   |delivery AT
Arne           | Arne     | DE | 2        | 2      | 2   | 2  | yes   |
ManiB          | Manfred  | DE | 5        | 5      | 5   | 5  | yes   |
Gerad          | Gerad    | DE | 3        | 3      | 3   | 3  | yes   |
Martin H.      | Martin   | DE | 1        | -      | -   | -  | yes   |
karlelch       | Thomas   | DE | 1        |        |     |    |       |
Frank N. Furter| Frank    | DE | 1        | 1      | 1   | 1  | yes   |
tom_g          | Thomas   | CH | 1        | 1      | -   | -  | yes   |delivery DE
ville56        | Gerald   | AT | 1        | 1      | 1   | 1  |       |
                                22         18     18   18


Payment can be made via PayPal or bank transfer. More details to follow.
Die Zahlung kann per PayPal oder Banküberweisung erfolgen. Details später.

Please write "yes" if you're still in – thanks.
Bitte "yes" bei "August OK?" eintragen wer dabei bleibt, danke.

The housing appears to be cheapest at DigiKey:
Das Gehäuse scheint bei DigiKey am günstigsten zu: https://www.digikey.de/de/products/detail/hammond-manufacturing/RM2015S/2094831

PS Immer noch kein PSRAM vefügbar, falls einer vor mir die Verfügbarkeit feststellt gerne eine kurze Info, danke!
There’s still no PSRAM available; if anyone spots it becoming available before I do, please let me know briefly – thanks!

25 ist das neue Limit! Zur Zeit sind noch 2-3 Boards verfügbar.
25 is the new limit! There are currently 2–3 boards still available.

karlelch

Guru

Joined: 30/10/2014
Location: Germany
Posts: 335
Posted: 09:42pm 08 Jul 2026
Copy link to clipboard
Print this post

Yes (sorry for the delay)

Thanks
Thomas (Euler) aka karlelch

ville56
Guru

Joined: 08/06/2022
Location: Austria
Posts: 550
Posted: 04:31am 09 Jul 2026
Copy link to clipboard
Print this post


User           | Name     |Loc.|No.ofPC3s|hdmi2VGA|panels|case|Aug.OK?|comment
homa57         | Matthias | DE | 2        | 1      | 2   | 2  | yes   |
v.lenzer       | Joachim  | DE | 2        | 2      | 2   | 2  |       |
bigfix         | Guenter  | AT | 3        | 3      | 3   | 3  | yes   |delivery AT
Arne           | Arne     | DE | 2        | 2      | 2   | 2  | yes   |
ManiB          | Manfred  | DE | 5        | 5      | 5   | 5  | yes   |
Gerad          | Gerad    | DE | 3        | 3      | 3   | 3  | yes   |
Martin H.      | Martin   | DE | 1        | -      | -   | -  | yes   |
karlelch       | Thomas   | DE | 1        |        |     |    |       |
Frank N. Furter| Frank    | DE | 1        | 1      | 1   | 1  | yes   |
tom_g          | Thomas   | CH | 1        | 1      | -   | -  | yes   |delivery DE
ville56        | Gerald   | AT | 1        | 1      | 1   | 1  | yes   |delivery AT
                               22         18     18   18

added my "yes".

Ad PSRAM: if no PSRAM will be available, as I have some left over from earlier experiments, I would manually solder it. So no PSRAM would be no showstopper for me if the order is placed without them.

Gerald

P.S. I think the totals are incorrect, but I didn't want to tweak other lines as my own ...
Edited 2026-07-09 14:34 by ville56

73 de OE1HGA, Gerald

v.lenzer
Senior Member

Joined: 04/05/2024
Location: Germany
Posts: 123
Posted: 06:50am 09 Jul 2026
Copy link to clipboard
Print this post

User           | Name     |Loc.|No.ofPC3s|hdmi2VGA|panels|case|Aug.OK?|comment
homa57         | Matthias | DE | 2        | 1      | 2   | 2  | yes   |
v.lenzer       | Joachim  | DE | 2        | 2      | 2   | 2  | yes   |
bigfix         | Guenter  | AT | 3        | 3      | 3   | 3  | yes   |delivery AT
Arne           | Arne     | DE | 2        | 2      | 2   | 2  | yes   |
ManiB          | Manfred  | DE | 5        | 5      | 5   | 5  | yes   |
Gerad          | Gerad    | DE | 3        | 3      | 3   | 3  | yes   |
Martin H.      | Martin   | DE | 1        | -      | -   | -  | yes   |
karlelch       | Thomas   | DE | 1        |        |     |    |       |
Frank N. Furter| Frank    | DE | 1        | 1      | 1   | 1  | yes   |
tom_g          | Thomas   | CH | 1        | 1      | -   | -  | yes   |delivery DE
ville56        | Gerald   | AT | 1        | 1      | 1   | 1  | yes   |delivery AT
                              22         18     18   18

Also a "yes" from me! It's already in the list.

What Gerald wrote applies to me as well:

"Ad PSRAM: if no PSRAM will be available, as I have some left over from earlier experiments, I would manually solder it. So no PSRAM would be no showstopper for me if the order is placed without them."
Edited 2026-07-09 16:52 by v.lenzer
Best wishes! Joachim

karlelch

Guru

Joined: 30/10/2014
Location: Germany
Posts: 335
Posted: 09:29am 09 Jul 2026
Copy link to clipboard
Print this post

I completed my entry of the table::


User           | Name     |Loc.|No.ofPC3s|hdmi2VGA|panels|case|Aug.OK?|comment
karlelch       | Thomas   | DE | 1       | -      | 1    | 1  | yes   |delivery DE


Thanks and best
Thomas

homa

Guru

Joined: 05/11/2021
Location: Germany
Posts: 650
Posted: 05:53pm 09 Jul 2026
Copy link to clipboard
Print this post


User           | Name     |Loc.|No.ofPC3s|hdmi2VGA|panels|case|Aug.OK?|comment
homa57         | Matthias | DE | 2        | 1      | 2   | 2  | yes   |
v.lenzer       | Joachim  | DE | 2        | 2      | 2   | 2  | yes   |
bigfix         | Guenter  | AT | 3        | 3      | 3   | 3  | yes   |delivery AT
Arne           | Arne     | DE | 2        | 2      | 2   | 2  | yes   |
ManiB          | Manfred  | DE | 5        | 5      | 5   | 5  | yes   |
Gerad          | Gerad    | DE | 3        | 3      | 3   | 3  | yes   |
Martin H.      | Martin   | DE | 1        | -      | -   | -  | yes   |
karlelch       | Thomas   | DE | 1        | -      | 1   | 1  | yes   |
Frank N. Furter| Frank    | DE | 1        | 1      | 1   | 1  | yes   |
tom_g          | Thomas   | CH | 1        | 1      | -   | -  | yes   |delivery DE
ville56        | Gerald   | AT | 1        | 1      | 1   | 1  | yes   |delivery AT
----------------------------------------------------------------------------------
                                22         19       20    20
must be ordered by me            25         20       23    23


panels?
https://www.thebackshed.com/forum/ViewTopic.php?TID=17301&PID=236160#236160
and
https://www.thebackshed.com/forum/ViewTopic.php?FID=16&TID=18967



Right, everyone’s on board – brilliant! I’ll place the order in calendar week 32 – that’s early August – subject to all components being in stock. I’ll get in touch shortly before then with the exact costs and payment options.
There are now a maximum of three boards and one adapter with a casing left to allocate. Everything else has been reserved and I don’t intend to order any more.

Okay, alle sind dabei, prima! Ich werde die Bestellung vorbehaltlich der Verfügbarkeit aller Bauteile in KW 32, also Anfang August, aufgeben. Ich melde mich kurz vorher mit den genauen Kosten und den Bezahlmöglichkeiten.
Es sind jetzt maximal noch drei Boards und ein Adapter mit Gehäuse zu vergeben. Alles andere ist reserviert und ich möchte nicht weiter aufstocken.

Matthias

ManiB
Senior Member

Joined: 12/10/2019
Location: Germany
Posts: 144
Posted: 08:25pm 09 Jul 2026
Copy link to clipboard
Print this post

Have you ever thought about ordering the PCBs in black instead of green? They cost a few cents extra, but they look so much more high-quality—and black is beautiful. The PCB panels should be black too, of course—what else? ;)



hhtg1968
Senior Member

Joined: 25/05/2023
Location: Germany
Posts: 206
Posted: 09:36pm 09 Jul 2026
Copy link to clipboard
Print this post

I would like to join in for 1 board.

     Page 2 of 3
Print this page
The Back Shed's forum code is written, and hosted, in Australia.
© JAQ Software 2026
