Forum Index : Microcontroller and PC projects : (DM) New Mega-100 Preliminary Specs.

Author Message
donmck

Guru

Joined: 09/06/2011
Location: Australia
Posts: 1313
Posted: 02:27pm 24 Nov 2011
Copy link to clipboard
Print this post

(DM) New Mega-100 Preliminary Specs.

Tsvetan of Olimex has just announced the specs for the 100 pin DuinoMite.
This includes features and schematics.

http://www.kenseglerdesigns.com/cms/forums/viewtopic.php?f=3 &t=12

Prices and availability not yet available.

Cheers Don...
https://www.dontronics.com

DuinoMiteMegaAn
Senior Member

Joined: 17/11/2011
Location: Australia
Posts: 231
Posted: 06:31pm 24 Nov 2011
Copy link to clipboard
Print this post

Don,

The specs for the New Mega-100 is awesome BUT since the DuinoMite Mega only started to ship in the last few weeks and customers are buying them now without a completed user manual then shouldn't there be a very high priority effort to complete the Mega docs for the present users?

If I was a prospective buyer of the DuinoMite Mega and saw the specs for a newer 100 pin version then I would probably hold off in buying the "standard version" and wait until the 100 pin version comes out.

You are really doing your customers a dis-favor by advertising a newer version. May I suggest that when the 100 pin version is completed with "all the proper docs", only then should this new version should be advertised to the general public. After all, the only main difference, between the two versions is Ethernet and more GPIO. IMHO - In my humble opinion.

donmck

Guru

Joined: 09/06/2011
Location: Australia
Posts: 1313
Posted: 06:43pm 24 Nov 2011
Copy link to clipboard
Print this post

  DuinoMiteMegaAn said   Don,

The specs for the New Mega-100 is awesome BUT since the DuinoMite Mega only started to ship in the last few weeks and customers are buying them now without a completed user manual then shouldn't there be a very high priority effort to complete the Mega docs for the present users?

If I was a prospective buyer of the DuinoMite Mega and saw the specs for a newer 100 pin version then I would probably hold off in buying the "standard version" and wait until the 100 pin version comes out.

You are really doing your customers a dis-favor by advertising a newer version. May I suggest that when the 100 pin version is completed with "all the proper docs", only then should this new version should be advertised to the general public. After all, the only main difference, between the two versions is Ethernet and more GPIO. IMHO - In my humble opinion.


I'll have to throw the question of the user manual over to Tsvetan Andy, as I believe he is creating one.

The reason he wanted to show what was possible now, was to allow users to give input into the design phase, as this isn't an ad for the new unit, it is to ask users their thoughts on what can be done, or what they would like to be done with it.

I read it the same as you Andy, Ethernet and more GPIO, but perhaps I am missing something.

Cheers Don...



Edited by donmck 2011-11-26
https://www.dontronics.com

JohnS
Guru

Joined: 18/11/2011
Location: United Kingdom
Posts: 3800
Posted: 08:37pm 24 Nov 2011
Copy link to clipboard
Print this post

One minute it's the eMega then the Mega-100.

They do need to write the user manuals. Think they're 3 or 4 behind :(

And I'm unclear where the source code for such as MMBasic and fairly oft-mentioned examples are. AWOL, I think.

I suppose the eMega / Mega-100 could be more like the MM except then it won't be as much like the DMs.... There again, maybe there will be so many pins that it won't matter.

ksdesigns

Senior Member

Joined: 25/06/2011
Location: United States
Posts: 143
Posted: 10:13pm 24 Nov 2011
Copy link to clipboard
Print this post


CLICK HERE
then on the left click DUINO
then again on the left click DUINOMITE-MEGA
scroll down to the bottom of the screen
lots of links there

if you need screen shots of the steps just ask :)
ken

JohnS
Guru

Joined: 18/11/2011
Location: United Kingdom
Posts: 3800
Posted: 10:55am 25 Nov 2011
Copy link to clipboard
Print this post

Yeah - still no user manual, the samples for various boards aren't there (I see Mick et al have now done some), and that's 2.7 of Basic instead of 2.7B

No source for the firmware updater - will that be available please?

John

bigmik

Guru

Joined: 20/06/2011
Location: Australia
Posts: 2914
Posted: 01:41pm 25 Nov 2011
Copy link to clipboard
Print this post

  JohnS said   the samples for various boards aren't there (I see Mick et al have now done some), and that's 2.7 of Basic instead of 2.7B


John


Hi John,

Sorry I may have had a bit too much water (12 year old bottled in Scotland), I am not sure what that referrence to me means..

In the vein of Ms Hanson.. `Please explain'

Mick
Mick's uMite Stuff can be found >>> HERE (Kindly hosted by Dontronics) <<<

ksdesigns

Senior Member

Joined: 25/06/2011
Location: United States
Posts: 143
Posted: 01:59pm 25 Nov 2011
Copy link to clipboard
Print this post

  JohnS said   Yeah - still no user manual, the samples for various boards aren't there (I see Mick et al have now done some), and that's 2.7 of Basic instead of 2.7B

No source for the firmware updater - will that be available please?

John


Microchip Applications Libraries
The Firmware updater is in there we just changed the vid/pid
ken

JohnS
Guru

Joined: 18/11/2011
Location: United Kingdom
Posts: 3800
Posted: 05:41pm 25 Nov 2011
Copy link to clipboard
Print this post

  bigmik said  Hi John,

Sorry I may have had a bit too much water (12 year old bottled in Scotland), I am not sure what that referrence to me means..

In the vein of Ms Hanson.. `Please explain'

Mick

I was thinking of Don's post about the LCD & buttons. Your name looked to occur often here: http://www.themaximitecomputer.com/max/Programs/index.php?di r=Hardware%2FDontronics%2FLCD%2F

JohnEdited by JohnS 2011-11-27

JohnS
Guru

Joined: 18/11/2011
Location: United Kingdom
Posts: 3800
Posted: 05:46pm 25 Nov 2011
Copy link to clipboard
Print this post

  ksdesigns said   Microchip Applications Libraries
The Firmware updater is in there we just changed the vid/pid
ken

Thanks.

bigmik

Guru

Joined: 20/06/2011
Location: Australia
Posts: 2914
Posted: 10:59pm 25 Nov 2011
Copy link to clipboard
Print this post

  JohnS said
I was thinking of Don's post about the LCD & buttons. Your name looked to occur often here:

John


Thanks John,

Don sees me as his right hand man, he actually vouched for me at my current job, (Tabcorp, been there now over 26 years) He is long gone, I am still trapped in the employment rutt...

I tend to think of myself more as the litttle old fella who was Benny Hill's right hand man and Don keeps slapping me on the head. (boy have I got a headache)






Mick's uMite Stuff can be found >>> HERE (Kindly hosted by Dontronics) <<<
