Forum Index : Microcontroller and PC projects : DuinoMite, a Maximite Compat from Olimex

     Page 1 of 5
Author Message
donmck

Guru

Joined: 09/06/2011
Location: Australia
Posts: 1313
Posted: 07:22pm 02 Sep 2011
Copy link to clipboard
Print this post

DuinoMite, a Maximite Compatible from Olimex.

Glenn, firstly please forgive me for starting a new thread. I wanted to drop the mention of the old naming convention quickly, as Geoff Graham has plans for using this in future Silicon Chip Articles.

Note****
I created the slogan: Maximite is Highly Explosive. The others are just Microcomputers.
Google the definition of "Maximite" It is an Explosive.
My friend Mick Gulovsen came up with the play on words "DuinoMite". Nice work Mick.

So the new names are:
DuinoMite-PC
DuinoMite-Mega
DuinoMite-Mega-I/O
DuinoMite-Mini
DuinoMite-Shield

The old URL to my blog still works, however the new URL is:
http://www.themaximitecomputer.com/duinomite-a-maximite-comp atible-from-olimex/

05:20 and all finished.

Now, what will we do after breakfast?

Cheers Don...

https://www.dontronics.com

jman

Guru

Joined: 12/06/2011
Location: New Zealand
Posts: 711
Posted: 07:30pm 02 Sep 2011
Copy link to clipboard
Print this post

Hi Don

The pictures are broke

John

donmck

Guru

Joined: 09/06/2011
Location: Australia
Posts: 1313
Posted: 07:32pm 02 Sep 2011
Copy link to clipboard
Print this post

  jman said   Hi Don

The pictures are broke

John


which pictures John?
URLs?

I will fix asap.

Cheers Don...
https://www.dontronics.com

jman

Guru

Joined: 12/06/2011
Location: New Zealand
Posts: 711
Posted: 07:35pm 02 Sep 2011
Copy link to clipboard
Print this post

These ones

http://www.themaximitecomputer.com/duinomite-a-maximite-comp atible-from-olimex/
on the the page the pictures dont show looks like wrong

This the link http://www.themaximitecomputer.com/max/Programs/Hardware/Don tronics/Olimex/Boxed/boxed.jpg

Hope this helps

John

donmck

Guru

Joined: 09/06/2011
Location: Australia
Posts: 1313
Posted: 07:42pm 02 Sep 2011
Copy link to clipboard
Print this post




Thanks John, sorry,

Because it is all new names, I have changed those names in all the files to suit.

Schematics and all other relevant files are available from:
http://www.themaximitecomputer.com/max/Programs/
Then Select Hardware > Dontronics > Olimex

Cheers Don...
https://www.dontronics.com

donmck

Guru

Joined: 09/06/2011
Location: Australia
Posts: 1313
Posted: 07:56pm 02 Sep 2011
Copy link to clipboard
Print this post


I just got a PM from John.

Sorry John, you have sent me two now old URLs.
They no longer exist.

You need to do this:
Schematics and all other relevant files are available from:
http://www.themaximitecomputer.com/max/Programs/
Then Select Hardware > Dontronics > Olimex

and the new URLs will be exposed.

Cheers Don...

https://www.dontronics.com

donmck

Guru

Joined: 09/06/2011
Location: Australia
Posts: 1313
Posted: 07:59pm 02 Sep 2011
Copy link to clipboard
Print this post


my apologies John, I just realized what you were really saying.

You are a beta tester.

Will fix now.

Cheers Don...
https://www.dontronics.com

jman

Guru

Joined: 12/06/2011
Location: New Zealand
Posts: 711
Posted: 08:00pm 02 Sep 2011
Copy link to clipboard
Print this post

Hi Don

Yip
But on your main page http://www.themaximitecomputer.com/
When i scroll down the pics are missing




donmck

Guru

Joined: 09/06/2011
Location: Australia
Posts: 1313
Posted: 08:10pm 02 Sep 2011
Copy link to clipboard
Print this post



Thanks John, got caught up in the old Catch-22 situation.

Changed the HTML code to suit the new names, then changed the file names, and it didn't match my original HTML code.

All sorted now, and makes sense.

Must be time for my morning walk.
I reckon I may catch a slow granny going up the hill this morning.

Cheers Don...
https://www.dontronics.com

jman

Guru

Joined: 12/06/2011
Location: New Zealand
Posts: 711
Posted: 08:12pm 02 Sep 2011
Copy link to clipboard
Print this post

Winner

Now go catch that granny


John

vasi

Guru

Joined: 23/03/2007
Location: Romania
Posts: 1697
Posted: 08:33pm 02 Sep 2011
Copy link to clipboard
Print this post

DuinoMite can be a Dynamite too!
Hobbit name: Togo Toadfoot of Frogmorton
Elvish name: Mablung Miriel
Beyound Arduino Lang

donmck

Guru

Joined: 09/06/2011
Location: Australia
Posts: 1313
Posted: 09:30pm 02 Sep 2011
Copy link to clipboard
Print this post

  vasi said   DuinoMite can be a Dynamite too!


DuinoMite is a Dynamite Maximite Compatible.

A great name for a great product?

Cheers Don...
https://www.dontronics.com

sparkey

Senior Member

Joined: 15/06/2011
Location: Australia
Posts: 819
Posted: 10:05pm 02 Sep 2011
Copy link to clipboard
Print this post

cool don regards sparkey.....

yes very nice unit there it will be my next aquirement will wait for this one ..i also like how you can add on the dino gear thats so cool will u be supplying the cases as well Edited by sparkey 2011-09-04
technicians do it with least resistance

Gizmo

Admin Group

Joined: 05/06/2004
Location: Australia
Posts: 5078
Posted: 10:58pm 02 Sep 2011
Copy link to clipboard
Print this post

Don you must be burning a lot of late night oil! Well done, good work.

Glenn
The best time to plant a tree was twenty years ago, the second best time is right now.
JAQ

donmck

Guru

Joined: 09/06/2011
Location: Australia
Posts: 1313
Posted: 11:07pm 02 Sep 2011
Copy link to clipboard
Print this post

Thanks Guys,

Sparkey, there will be a case supplied with the PC version, in fact it may be the only way to order it. Not 100% sure just yet.

Glenn, just wondering if I should ask you to lock the previous thread I moved this thread from, so there is no more traffic, or confusion on product names.

BTW
I just registered http://www.duinomite.com/

Cheers Don...Edited by donmck 2011-09-04
https://www.dontronics.com

Gizmo

Admin Group

Joined: 05/06/2004
Location: Australia
Posts: 5078
Posted: 11:15pm 02 Sep 2011
Copy link to clipboard
Print this post

Sure Don, done.
The best time to plant a tree was twenty years ago, the second best time is right now.
JAQ

donmck

Guru

Joined: 09/06/2011
Location: Australia
Posts: 1313
Posted: 11:20pm 02 Sep 2011
Copy link to clipboard
Print this post


Thanks very much Glenn, I know that will keep Geoff and Leo happy.

Cheers Don...
https://www.dontronics.com

sparkey

Senior Member

Joined: 15/06/2011
Location: Australia
Posts: 819
Posted: 04:26am 03 Sep 2011
Copy link to clipboard
Print this post

will the latest version of the hex code enable the new features on your board
don... that there is now with gerards help and geoff.. version 2.5d as far as i know "d" is the latest ... will the extra features need more code written......regards sparkey.....
technicians do it with least resistance

donmck

Guru

Joined: 09/06/2011
Location: Australia
Posts: 1313
Posted: 04:44am 03 Sep 2011
Copy link to clipboard
Print this post

  sparkey said   will the latest version of the hex code enable the new features on your board
don... that there is now with gerards help and geoff.. version 2.5d as far as i know "d" is the latest ... will the extra features need more code written......regards sparkey.....


Ken Segler will be able to update the first DuinoMite boards to the latest version for initial release.

Hopefully in the near future, MM-Basic will become far more stable, and not require the input that Geoff has had to provide in recent months.

As source code will always be available, and there is no shortage of very talented people on this forum, I don't see the DuinoMite boards lagging behind.

It will be very much user driven, so I really don't know what direction it will all develop towards, hardware or software wise.

If people want routines, they will get written.

I also see many new MM-Basic programs being created to drive all of the potential Arduino shields that are around today, as well as in the future.

If it can be created in C, then it can be created in Basic.
Well, only limitation may be speed throughput on time critical applications.

Machine language drivers can overcome these time critical bottle necks, but will need integrating into the memory of the PIC32 in some way. This is way past my current knowledge, but it can all be done.

If only I was 40, NO, 50 years younger.

Cheers Don...



https://www.dontronics.com

VK6MRG

Guru

Joined: 08/06/2011
Location: Australia
Posts: 347
Posted: 09:24am 03 Sep 2011
Copy link to clipboard
Print this post

All looks good. One disappointing thing is the use of the 64 pin PIC32 and not the 100 pin PIC32 chip. Maybe next time.
Its easier to ask forgiveness than to seek permission!

............VK6MRG.............VK3MGR............

     Page 1 of 5
