Forum Index : Microcontroller and PC projects : PicoMiteHDMIUSB motherboard reference design

Page 7 of 7

Author

Message

mclout999
Guru

Joined: 05/07/2020
Location: United States
Posts: 469

Posted: 02:45am 06 Nov 2024

Copy link to clipboard

Print this post

sorry repost. I wish we could delete them.
Edited 2024-11-06 12:47 by mclout999

phil99

Guru

Joined: 11/02/2018
Location: Australia
Posts: 2129

Posted: 03:24am 06 Nov 2024

Copy link to clipboard

Print this post

Try pauses between each read, the hardware may need time to read the next value. Test various values to find the minimum.

Wii Nunchuck OPEN
P = 20 'pause length mS
Do
Print DEVICE(NUNCHUCK C);
Pause P
Print DEVICE(NUNCHUCK Z);
Pause P
Print DEVICE(NUNCHUCK JX);
Pause P
Print DEVICE(NUNCHUCK JY)
Pause P
Loop

mclout999
Guru

Joined: 05/07/2020
Location: United States
Posts: 469

Posted: 02:32pm 06 Nov 2024

Copy link to clipboard

Print this post

phil99 said Try pauses between each read, the hardware may need time to read the next value. Test various values to find the minimum.

Wii Nunchuck OPEN
P = 20 'pause length mS
Do
Print DEVICE(NUNCHUCK C);
Pause P
Print DEVICE(NUNCHUCK Z);
Pause P
Print DEVICE(NUNCHUCK JX);
Pause P
Print DEVICE(NUNCHUCK JY)
Pause P
Loop

Thanks will do. Next issue. Matherp gave the labels for the inputs for the Nunchuck but not for the classic controller. I wanted to test those next. The CMM3 Manual has a list of what he used there are those, right for the DEVICE(CLASSIC X)?

EDIT: even with this code I get the message to enter pin or 0 to restart when you break out of the program. WHAT IS THAT and why is it happening?
Edited 2024-11-07 02:35 by mclout999

Volhout
Guru

Joined: 05/03/2018
Location: Netherlands
Posts: 4213

Posted: 03:57pm 06 Nov 2024

Copy link to clipboard

Print this post

Hi,

The WII classic controller is documented in the 5.08.00 user manual (Geoff's site). Search for "WII" in the document. I think it is page 111.

All changes since then are in this writeup

summary of all changes

Thanks to tha hard work of Mixtel90

Volhout
Edited 2024-11-07 02:02 by Volhout

PicomiteVGA PETSCII ROBOTS

Mixtel90

Guru

Joined: 05/10/2019
Location: United Kingdom
Posts: 6761

Posted: 04:40pm 06 Nov 2024

Copy link to clipboard

Print this post

See manual 5.08.00 and later
DEVICE WII OPEN [,interrupt]
Opens a WII Classic controller and implements background polling of the
device. The Wii Classic must be wired to the pins specified by OPTION
SYSTEM I2C which is a prerequisite. Open attempts to talk to the Wii
Classic and will return an error if not found. If found the firmware will
sample the Wii data in the background at a rate of 50Hz. If an optional
user interrupt is specified this will be triggered if any of the buttons
changes (both on and off).
See the DEVICE function for how to read data from the Wii Classic.

Mick

Zilog Inside! nascom.info for Nascom & Gemini
Preliminary MMBasic docs & my PCB designs
